3D Printer - Creality 3D Ender-5 Plus - 350x350x400mm

As the name might suggest, the Ender 5 Plus offers a larger build volume. With 350x350x400mm, it is by far the biggest Ender yet and putting in more in...
26-00024384
Gross Weight: 35kg
Warranty: 1 Year Manufacturer Warranty
Company: Creality 3D
Part Number: Ender-5 Plus
Made in: China
Out of Stock
Product out of stock
No stock in retail store
599.00
Without VAT 483.07

We (GRobotronics) will add your email address to a special mailing list for this product. Once the product is in stock, you’ll get an email about it automatically, and your email address will be removed from the product’s mailing list.

The data will be visible to some members of our staff. If you’d like to have your personal data removed, send an email to dpo@grobotronics.com.

If you believe that your personal data has been misused, you have the right to lodge a complaint with a supervisory authority. We’re obliged by EU General Data Protection Regulation to let you know about this right; we don’t actually intend to misuse your data.

Add to Cart
WISHLIST COMPARE

DESCRIPTION

As the name might suggest, the Ender 5 Plus offers a larger build volume. With 350x350x400mm, it is by far the biggest Ender yet and putting in more in league with the CR-10 series.

A bigger build volume, a new bed-leveling probe, improved components: The Creality Ender 5 Plus wants to surpass its little brother.

It’s Much Bigger

Well, pretty obvious, isn’t it? While the build volume of its “little brother” Ender 5 (220x220x300mm) is enough for most prints, it is always convenient to have extra space for bigger tasks. The Ender 5 Plus offers precisely that. Its glass bed boasts an area of 350x350mm, while the Z-axis stretches to 400mm. That’s bigger than the print volume on a Creality’s CR-10S, which sat at 300x300x400mm.

As the machine’s measurements are already quite large – mostly due to its boxed-frame design (632x555x619mm), Creality thankfully designed the printer so that no components are stored outside of the printer itself; the power supply and filament spool both are located within the printer’s frame.

More Stability for the Z-Axis

Just like the Ender 5, the Plus also uses a Gantry design, meaning the print head is arranged at the top frame of the printer, with the print bed moving down on the Z-axis. Again, each axis has a dedicated stepper motor, and the Y-axis motor drives both belts at the same time – nothing much changed here. To provide sufficient stability to the Z-axis, the enlarged print bed is mounted on four rods and two lead screws, though, instead of the two rods used on the stock Ender 5.

This results in an overall smoother movement and fewer layer shifts. The Z-axes are mounted in the middle of the bed with large 8-mm-rods stabilizing each side — in theory, quite a clever way of getting smooth motions while keeping the stability.

Bed Leveling Probe

Furthermore, the Ender 5 Plus is finally equipped with an Antclabs’ contact-triggered BLTouch proximity sensor. Well, at least three quarters the print bed, as the probe is mounted about seven centimeters left of the extruder and measuring of the whole print bed is mechanically not possible. A firmware upgrade promised to deliver a solution. That being said, Creality is known to iterate the machines very fast. Until then, it’s back to manual bed-leveling. At least Creality installs large knobs, allowing for an easy turning of screws.

Filament Sensor

Just like the Ender 5, the Ender 5 Plus is also equipped with the, nowadays commonplace resume print function and, unlike the Ender 5, also features a filament runout sensor.

Naturally, if you plan on printing big objects most of the time, the Ender 5 Plus might be suited for you.



NOTES

  • Assembly is required.

SPECIFICATIONS

Extruder Compatibility:
  • CR10 (MK8 Hotend)
3D Printer Category:
  • Affordable
Printing Technology:
FFF (Fused Filament Fabrication)
Filament Diameter:
1.75mm
Layer Resolution:
50μm
Max. Print Speed:
150mm/sec
Precision:
±0.1mm
Extruder Quantity:
Single
Nozzle Quantity:
1
Max Nozzle Temp.:
260
Max Bed Temp.:
110
Heated Bed Type:
Glass
Leveling:
Automatic
Build Volume X:
350mm
Build Volume Y:
350mm
Build Volume Z:
400mm
Power Supply:
MeanWell
Supported Materials :
  • ABS (small parts)
  • PET
  • PLA
  • WOOD
File Format:
  • G-Code
  • OBJ
  • STL
Working Mode :
  • Offline (SD Card/USB Stick)
  • Online (USB)
WiFi Connectivity:
No

SPECIFICATIONS

  • Print Specifications
    • Nozzle diameter: 0.4mm can be in 0.2, 0.3mm
    • Max Traveling Speed: 180mm/s
  • Display
    • Touchscreen 4.3 inch
  • Software
    • Slicer: Cura (Works with Simplify3D not included)
    • Operating System: Windows/Mac/Linux
  • Mechanical
    • Chassis: Imported V-Slot Aluminum Bearings
  • Electrical
    • Input: AC 100-265V 50-60Hz
    • Output: DC 24V 25A 600W
    • Plug: EU Power Plug
  • Dimensions
    • 632x666x619mm
    • Weight: 23.8kg

FEATURES

  • Cube Frame 3D Printer: Very solid cube frame. Box Design with Overhead Gantry.
  • Ultra Large Printing Format: 350X350X400mm. Meet more of your printing requirement.  Your idea should not be confined. Achieve better print results and a larger print model at a time.
  • Auto Bed Leveling Pre-Installed: With BL Touch as configured. You just plug them in and start printing!it can precisely measure the tilt of the Bed surface, offers the automatic compensation for Z-axis for unevenness of the platform plate, easy to solve the printing failure caused by the unevenness of the platform and provide reliable operation with all build surfaces.
  • Top frame features: Dual Y-axis stepper motor and equipped with a 42-48 motor.  Dual Y-axis Synchronization. Strong Power Support and Smoother transmission, flexible and reliable.
  • Dual Z-Axis: Stable Z-axis Lead screw drive smoothly and steady. Movement of the build plate will be more stable.

VIDEO

Creality Ender-5 Plus Unboxing Build and Set Up!

In this video, we will show you the Creality latest new printer Ender-5 Plus unbox, build and set up.
