Potentiometer 5Kohm Plastic

by OEM
05-00069005
Company: OEM
Made in: China
Out of Stock
Product out of stock
Available in store
1.60
Without VAT 1.29

We (GRobotronics) will add your email address to a special mailing list for this product. Once the product is in stock, you’ll get an email about it automatically, and your email address will be removed from the product’s mailing list.

The data will be visible to some members of our staff. If you’d like to have your personal data removed, send an email to dpo@grobotronics.com.

If you believe that your personal data has been misused, you have the right to lodge a complaint with a supervisory authority. We’re obliged by EU General Data Protection Regulation to let you know about this right; we don’t actually intend to misuse your data.

Add to Cart
WISHLIST COMPARE

SPECIFICATIONS

Kind of potentiometer:
Single turn
Mounting:
THT
Resistance :
  • 5KΩ
Power:
0.2W
Tolerance:
±20%
Max. Operating Voltage:
250Volt

EXTRA SPECIFICATIONS

  • Resistance 5kΩ
  • Power 200mW
  • Mounting THT
  • Shaft diameter 6mm
  • Characteristics linear
  • Body material plastic
  • Track material carbon
  • Potentiometer features mono
  • Shaft surface knurled
  • Max. operating voltage 250V DC
  • Potentiometer series PC-16

DOCUMENTS
