Voltage Regulator L7915CV - 15V 1.5A

05-00079150
Made in: China
In Stock
Ships in 24 Hours
Available in store
0.4000
Without VAT 0.32
+
Our quantity discounts:
Quantity 10+ 100+ 1000+
Price 0.3200 0.2800 0.2401
WISHLIST COMPARE

SPECIFICATIONS

Output Voltage:
15Volt

EXTRA SPECIFICATIONS

  • Integrated circuit type voltage regulator
  • Polarity: Negative
  • Output voltage: -15V
  • Output current: 1.5A
  • Output Type: Fixed
  • Input Voltage MAX: -35 V
  • Input Voltage MIN: -17.5 V
  • Mounting Style: Through Hole
  • Mounting: THT
  • Case: TO220
  • Minimum Operating Temperature: 0 C
  • Maximum Operating Temperature: + 150 C
  • Load Regulation: 300 mV
  • Line Regulation: 300 mV
  • PSRR / Ripple Rejection - Typ: 60 dB
  • Number of Outputs: 1 Output

Dimensions

  • 15.75x10.4x4.6 mm
