74HC574 Octal D Flip-Flop

in category Shift Registers

The 74HC574 is an octal D-type flip-flops featuring separate D-type inputs for each flip-flop and 3-state outputs for bus-oriented applications.

05-00074574
Made in: Taiwan
In Stock
Ships in 24 Hours
Available in store
0.60
Without VAT 0.48
+
Our quantity discounts:
Quantity 10+ 100+ 1000+
Price 0.4800 0.4200 0.3600
WISHLIST COMPARE

DESCRIPTION

The 74HC574 is an octal D-type flip-flops featuring separate D-type inputs for each flip-flop and 3-state outputs for bus-oriented applications. A clock (CP) and an output enable (OE) input are common to all flip-flops. The 8 flip-flops will store the state of their individual D-inputs that meet the set-up and hold times requirements on the LOW-to-HIGH CP transition. When OE is LOW the contents of the 8 flip-flops are available at the outputs. When OE is HIGH, the outputs go to the high-impedance OFF-state. Operation of the OE input does not affect the state of the flip-flops.

Specifications:

  • Integrated circuit type digital
  • Number of channels 8
  • Case DIP20
  • Mounting THT
  • Series HC

Documents:



SPECIFICATIONS

Case:
DIP20
