Gravity Analog Infrared CO2 Sensor (0-5000 ppm)

by DFROBOT
The concentration of carbon dioxide (0.03% usuallly) is related to daily life. Recently, there’s a study showing that the atmospheric CO2 content has...
25-00021900
Gross Weight: 0kg
Company: DFROBOT
Part Number: SEN0219
Made in: China
In Stock
Ships in 24 Hours
No stock in retail store
72.00
Without VAT 58.06
+
WISHLIST COMPARE

DESCRIPTION

The concentration of carbon dioxide (0.03% usuallly) is related to daily life. Recently, there’s a study showing that the atmospheric CO2 content has reached 0.0385% (385 ppm) which is the highest value since 2.1 million years. The raise of atmospheric CO2 content to some extent results in global climate change. How to accurately measure the carbon dioxide gas concentration is becoming a universal research topic.

DFRobot released its latest high-precision analog infrared arduino CO2 sensor. The effectively measuring range is from 0 to 5000ppm. This sensor is based on non-dispersive infrared (NDIR) technology and has good selectivity and oxygen-free dependency. Besides, its service life could up to 5 years! It integrates temperature compensation and support DAC output. Most importantly, the product is easy to use; it is compatible with all types of microcontrollers such as Arduino with ADC function.

In addition, this Gravity: Analog Infrared CO2 Sensor For Arduino (0~5000 ppm) is a high-performance sensor that combines technology of mature infrared absorption gas detection with precision optical circuit design as well as sophisticated circuit design. It has characteristics such as high sensitivity, high resolution, low power consumption, fast response, anti-water vapor interference, no poisoning, high stability and long life.

This Gravity: Analog Infrared CO2 Sensor is able to directly compatible with the Arduino IO expansion board thanks to its external DFRobot Gravity interface. This character simplify the use of the sensor as it is plug and play and no need additional wiring.

This CO2 Sensor could be widely used in HVAC, indoor air quality monitoring, industrial process and security protection monitoring, agriculture and animal husbandry production process monitoring.

THE PACKAGE INCLUDES

  • 1x Gravity: Analog Infrared CO2 Sensor For Arduino
  • 1x Analog Sensor Cable for Arduino



LCD Keypad Shield with Infrared Co2 Sensor

This is a 0~5000ppm CO2 sensor with analog output. It supports Arduino and other microcontrollers with ADC function. In addition, we also have a 0~50000 ppm wide range infrared sensor with Gravity UART interface, Compatible with Arduino, Raspberry Pi and other microcontrollers: Gravity: UART Infrared CO2 Sensor (0~50000ppm).

SPECIFICATIONS

Sensor Type:
  • Gas
Typical Input Voltage:
  • 5VDC
Oparating Current:
150mA
Interface:
  • Analog
Communication Protocol:
  • Without

SPECIFICATIONS

  • Gas Detection: Carbon Dioxide
  • Operating Voltage: 4.5 - 5.5V DC
  • Average Current: <60mA @ 5V
  • Peak Current: 150mA @ 5V
  • Output Signal: Analog output (0.4 ~ 2V)
  • Measuring Range: 0 ~ 5000ppm
  • Accuracy: ± (50ppm + 3% reading)
  • Preheating Time: 3min
  • Response Time: 120s
  • Operating Temperature: 0 - 50 ℃
  • Operating Humidity: 0 - 95% RH (no condensation)
  • Service Life: >5 years
  • Size: 37x69mm
  • Weight: 34g

FEATURES

  • Waterproof and anti-corrosion
  • High sensitivity
  • Low power consumption
  • Excellent stability
  • Temperature compensation
  • Excellent linear output
  • High cycle life
  • Anti-water vapor interference
  • No poisoning
