Pinion Gear 32P - 20T, 1/4" Bore

This 1/4" bore, 32 pitch pinion gear attaches directly to any 1/4"  diameter gear motor or stepper motor output shaft, Or attach to a 1/4"  diameter...
17-00615246
Volumetric weight: 0.01kgs
Company: Servocity
Made in: USA
In Stock
Ships in 24 Hours
No stock in retail store
9.90
Without VAT 7.98
+
WISHLIST COMPARE

DESCRIPTION

This 1/4" bore, 32 pitch pinion gear attaches directly to any 1/4" diameter gear motor or stepper motor output shaft, Or attach to a 1/4" diameter precision shafting. Simply slide them on and tighten the 10-32 set screw. This gear have a 20 degree pressure angle. Manufactured from hardened brass gear stock.  The set screw requires a 3/32” Hex Key (sold separately).

SPECIFICATIONS

Gear Type:
  • Pinion Gear
Number ot Teeth:
20
Pitch of Teeth:
32P
Inside Diameter:
6.35mm
Outside Diameter:
17.47mm
Material:
Brass

EXTRA SPECIFICATIONS

  • Product Weight: 0.45 oz / 12.7g
  • Material: Hardened Brass
  • Pitch Diameter: 0.625"
  • Number of teeth: 20T
  • Bore: 1/4"

Dimensions
