DFRobot URM15 Ultrasonic Distance Sensor – RS485, 30-500cm

Κωδικός:

25-00012519

Part Number: SEN0519

ΚατασκευαστήςDFRobot Part NumberSEN0519

Εξαντλημένο

€134⁹⁰

Κάνε μια ερώτηση

Διαθεσιμότητα Καταστημάτων

Πληρωμή & Μεταφορικά

Περιγραφή
Χαρακτηριστικά

DFRobot URM15 is an ultrasonic ranging sensor with an IP65 waterproof probe that offers an effective measuring range of 30cm–500cm (test on flat wall). It uses the RS485 interface that follows the standard Modbus-RTU protocol for reliable data communication. The sensor supports revisable slave addresses and serial parameters, which can be conveniently used with all kinds of industrial controlling machines.

In addition, the URM15 comes with a temperature compensation function. Users can select external or onboard temperature compensation to reduce the impact of ambient temperature on the measurement. The sensor adopts 75kHz ultrasonic transducer with a diameter of 40mm, so it features a relatively small measuring angle and high sensitivity.

What is the URM series?

The URM series is a range of ultrasonic distance measurement modules specifically designed for industrial control and robot control applications. These modules are equipped with internal temperature compensation functionality, allowing for accurate measurement of the distance between the sensor and the target object. They can be widely used in various scenarios, such as robot barrier navigation, liquid level detection, and obstacle avoidance designs.

Since the introduction of the first URM module in 2009, DFRobot has continuously released many models of the URM series of ultrasonic distance measurement modules. These modules cover a wide range of measurement distances, beam angles, accuracy levels, and interface options, catering to the requirements of different application scenarios.
