Indoor Air Quality Sensor - ENS160

25-00016695
SEN0537
CompanyDFRobot Part NumberSEN0537
In Stock
Ships in 24 Hours
3990 -20%
3192
Gropbotronics Store Availability
Availability in Retail Store
Payments & Shipping

This ENS160 Air Quality Sensor (I2C), based on ScioSense's new ENS160 sensor chip, is specifically designed for indoor air quality monitoring and offers detection of multiple IAQ data (TVOC, eCO2, AQI). The combination of the innovative TrueVOC™ technology and the metal oxide (MOX) technology brings this sensor superior accuracy, fast response, anti-interference, etc.

With intelligent on-chip algorithms, the ENS160 can directly output rich and easy-to-understand environmental data. Preheat the sensor 3 minutes before use to obtain accurate data more quickly. What's more, the built-in automatic baseline correction algorithm ensures the long-term stability of the sensor.

THE PACKAGE INCLUDES

  • 1x I2C ENS160 Air Quality Sensor

Connection Diagram

  • Supply Voltage: 3.3V~5V
  • Operating Current: 29mA
  • Preheat Time: <3 minutes
  • Communication Mode: I2C
  • I2C Address: 0x53
  • Operating Temperature: -10℃~80℃
  • Operating Humidity: 5%RH~95%RH (Non-condensing)
  • eCO2 Detection Range: 400ppm~65000ppm
  • TVOC Detection Range: 0ppb~65000ppb
  • Cable Length: 1m
  • The probe shape makes installation easier
  • Multiple IAQ outputs (TVOC, eCO2, AQI), various environmental data
  • Less than 3 minutes warm-up time, get data faster
  • Built-in algorithm, more accurate output
  • Automatic baseline correction, more stable for long-term use

Applications

  • Air purification/home automation device
  • Environmental pollution detection
  • HVAC/Ventilation System
  • Building Automation/Smart Thermostat
  • Electrical Appliance/Range Hood



Warranty
Δεν καλύπτεται με εγγύση απο τον Κατασκευαστή
Company
DFRobot
G. Weight
0.08kg
Sensor Type
  • Gas
Typical Input Voltage
  • 3.3VDC
  • 5VDC
Oparating Current
29mA
Interface
  • Digital
Communication Protocol
  • I2C
