Transformer 230V/12V 10VA

by Breve
05-00016105
Gross Weight: 0.3kg
Company: Breve
Made in: Poland
Out of Stock
Product out of stock
Available in store
4.90
Without VAT 3.95

We (GRobotronics) will add your email address to a special mailing list for this product. Once the product is in stock, you’ll get an email about it automatically, and your email address will be removed from the product’s mailing list.

The data will be visible to some members of our staff. If you’d like to have your personal data removed, send an email to dpo@grobotronics.com.

If you believe that your personal data has been misused, you have the right to lodge a complaint with a supervisory authority. We’re obliged by EU General Data Protection Regulation to let you know about this right; we don’t actually intend to misuse your data.

Add to Cart
WISHLIST COMPARE

SPECIFICATIONS

Type of transformer:
Encapsulated
Power:
10VA
Number of outputs:
1
Secondary voltage 1:
12V
Secondary winding current 1:
0.833A
Mounting:
PCB

EXTRA SPECIFICATIONS

  • Transformer type encapsulated
  • Power 10VA
  • Primary voltage 230V AC
  • Secondary voltage 1 12V
  • Secondary winding current 1 833.3mA
  • Mounting PCB
  • Pri./sec. insulation strength 4kV/60s
  • Sealing IP00
  • Conform to the norm PN-EN 61558-1:2000, PN-EN 61558-2-1:2000, PN-EN 61558-2-6:2000
  • Thermal class Ta40B
  • Secondary winding terminals 8-11
  • Primary winding terminals 1-6

Dimensions

  • A dimension 44mm
  • A1 dimension 27.5mm
  • A2 dimension 25mm
  • B dimension 52mm
  • C dimension 35mm
