Gravity Speech Synthesis Module V2.0

από DFROBOT
Would you like to add voice to your projects? Connect up this Speech Synthesis module, add a few couple of lines of code, then here goes, your project...
25-00016283
Ογκομετρικό βάρος: 0.01kg
Εγγύηση: Ως εξάρτημα, δεν καλύπτεται
Κατασκευαστής: DFROBOT
Part Number: DFR0760
Χώρα Προέλευσης: Κίνα
Διαθέσιμο
Αποστολή σε 24 ώρες
Χωρίς απόθεμα στο φυσικό κατάστημα
33.40
Χωρίς ΦΠΑ 26.94
+

ΠΕΡΙΓΡΑΦΗ

Would you like to add voice to your projects? Connect up this Speech Synthesis module, add a few couple of lines of code, then here goes, your project starts speaking. Both Chinese and English are "so easy" for this speech synthesis module. It also can broadcast the current time and environment data. Combined with a speech recognition module, you can easily have conversations with your projects! The module uses I2C and UART two communication modes, gravity interface, and is compatible with most main controllers on the market. Besides, the module already comes with a speaker, so you don't need to buy one.

ΣΗΜΕΙΩΣΕΙΣ

  • The addresses of the speech synthesis module and micro: bit motor driver board are the same, so they cannot be used together.
  • Support English and Chinese
  • V2.0 Function Updates:
    1. More natural pronunciation
    2. Fewer pronunciation errors for polyphone characters
    3. No option of speakers

Board Overview

Connection-Diagram

ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ

Εγγύηση:
Ως εξάρτημα, δεν καλύπτεται
Κατασκευαστής
:
DFROBOT
Part Number:
DFR0760
Μικτό Βάρος:
0.01kg
Χώρα Προέλευσης:
Κίνα
Τύπος Αισθητήρα:
  • Ήχου
Τυπική Τάση Εισόδου:
  • 3.3VDC
  • 5VDC
Διασύνδεση:
  • Ψηφιακή
Πρωτόκολλο Eπικοινωνίας:
  • I2C

ΕΠΙΠΛΕΟΝ ΧΑΡΑΚΤΗΡΙΣΤΙΚΑ

  • Power Supply: 3.3V~5V
  • Operating Current: <160mA
  • I2C Address: 0x40
  • Operating Temperature Range: -40℃~85
  • Dimension: 42x32mm

ΔΥΝΑΤΟΤΗΤΕΣ

  • Support Chinese, English, and mixed reading in Chinese and English
  • Comes with a Speaker
  • Gravity I2C/UART Communication
  • Support Multiple Text Control Identifiers

Applications

  • Robot Voice
  • Voice Broadcast
  • Voice Prompt
  • Text Reading
