Half-Bridge Driver IR2110PBF

05-00021100
IR2110PBF
ΚατασκευαστήςInfineon Part NumberIR2110PBF
Διαθέσιμο
Αποστολή σε 24 ώρες
€360
Infineon
+ −
Αγαπημένα
Κάνε μια ερώτηση
Gropbotronics Store Availability
Διαθεσιμότητα Καταστημάτων
Πληρωμή & Μεταφορικά
The IR2110/IR2113 are high voltage, high speed power MOSFET and IGBT drivers with independent high and low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. Logic inputs are compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. Propagation delays are matched to simplify use in high frequency applications. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which operates up to 500 or 600 volts.
  • Mounting Style: Through Hole
  • Package/Case: PDIP-14
  • Product: Half-Bridge Drivers
  • Number of Drivers: 2 Driver
  • Output Current: 2.5 A
  • Configuration: Non-Inverting
  • Rise Time: 35 ns
  • Fall Time: 25 ns
  • Supply Voltage - Max: 20 V
  • Supply Voltage - Min: 10 V
  • Propagation Delay - Max: 150 ns
  • Minimum Operating Temperature: - 40 C
  • Maximum Operating Temperature: + 125 C
  • Type: High and Low Side
  • Features: Independent
  • Number of Outputs: 2 Output
  • Logic Type: CMOS, TTL
  • Maximum Turn-Off Delay Time: 94 ns
  • Maximum Turn-On Delay Time: 120 ns
  • Operating Supply Current: 340 uA
  • Pd - Power Dissipation: 1.6 W
Θήκη
DIP14
Κατασκευαστής
Infineon
Part Number
IR2110PBF
Εγγύηση
Ως εξάρτημα, δεν καλύπτεται
Καθ. Βάρος
0.001kg
