Servo:Lite board for :MOVE mini

83-00005623
KITRONIK-5623
CompanyKitronik Part NumberKITRONIK-5623
In Stock
Ships in 24 Hours
1390
Gropbotronics Store Availability
Availability in Retail Store
Payments & Shipping

This Servo:Lite board for the BBC micro:bit can form the control hub for your robotics project, control up top three servos & it has 5 x RGB ZIP LEDs on board.

The Servo:Lite board for the BBC micro:bit is a simple board that allows you to easily connect and control low power servo motors (servo's must be capable of operating at 3.3V) using the BBC micro:bit. It is connected to the micro:bit using five bolts. Connect two servos in standard configuration and it can drive up to 3 servos if the addressable ‘ZIP’ LEDs aren’t needed.

It is powered by 3 AAA batteries and also supplies power to the BBC micro:bit, the board features an On / off switch so when it's not in use the batteries won't drain.

Video:

{youtube}4VyRh0aQeIQ{/youtube}



The board also features 5 x RGB individually addressable ZIP LEDs (NeoPixel compatible) and additional external ZIP LEDs can be connected to the board as required.

We've produced a range of tutorials and guides that can be found in the resources section below. We have guides detailing; how to control a third servo and how to write code for the on-board ZIP LEDs.

Features:

  • Connect two servos in standard configuration and can drive up to 3 servos if the addressable ‘ZIP’ LEDs aren’t needed
  • Powered by 3 AAA batteries that also supply power to the BBC microbit (not supplied)
  • On / off switch
  • 5 x RGB addressable ZIP LEDs (NeoPixel compatible). Additional external ZIP LEDs can be connected to the board

Contents:

  • 1 x Servo:Lite board with battery holder pre-fitted
  • 5 x M3x8 Counter sunk Pozi Steel screws
  • 1 x Perspex spacer

Dimensions:

  • Length: 55mm
  • Height: 52mm
  • Height: 17mm

Requires:

Resources:

Micro:bit Compatible
  • V1
  • V2
Company
Kitronik
Gross Weight
0.001kg
