Pi Zero Display e-Paper 2.13" HAT 250x122 Touch with case (White-Black)

31-00020716
2.13inch Touch e-Paper HAT (with case)
CompanyWaveshare Part Number2.13inch Touch e-Paper HAT (with case)
In Stock
Ships in 24 Hours
2860
Our quantity discounts:
Quantity
10+
Price
25.74
Gropbotronics Store Availability
Availability in Retail Store
Payments & Shipping

2.13inch Touch E-Paper E-Ink capacitive touch e-Paper display For Raspberry Pi Zero, 250×122 Pixels, with ABS Protection Case. With partial Refresh Support, Low Power, Wide Viewing Angle, Paper-Like Effect. Specialized for Raspberry Pi Zero / Zero W.

Advantages Of EINK

E-paper display utilizes microcapsule electrophoretic technology for displaying, the principle is: charged particles suspended in clear fluid will move to sides of microcapsule when electric field is applied, making the microcapsule become visible by reflecting ambient light, just as traditional printed paper.
E-paper display will clearly display images/texts under lamplight or natural light, requires no backlight, and features nearly up to 180° viewing angle. It is usually used as e-reader due to its paper-like effect.

Features At A Glance

  • 2.13" capacitive touch e-Paper display, 5-point touch, 250×122 pixels
  • Supports waken up by user-defined gesture
  • No backlight, keeps displaying last content for a long time even when power down
  • Ultra low power consumption, basically power is only required for refreshing
  • Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi Zero / Zero W
  • Comes with development resources and manual (examples for Raspberry Pi)

Fine Design, Precise Cut-Out

Highly Aligned Connectors, Rounded Corner Design, Slant Sides For Easily Standing

Heat Dissipation Holes On The Back

Combined With Thermal Tape, Effective Heat Dissipation

Standard Raspberry Pi 40PIN GPIO Header

Compatible With Raspberry Zero / Zero W

  • Operating Voltage: 3.3V
  • Grey Scale: 2
  • Interface: 3-wire SPI, 4-wire SPI
  • Partial Refresh Time: 0.3s
  • Outline Dimensions: 69.15 x38.90mm
  • Full Refresh Time: 2s
  • Display Size: 48.55 x23.70mm
  • Refresh Power: 26.4mW(typ.)
  • Dot Pitch: 0.194 x0.194mm
  • Standby Current: <0.01uA (almost none)
  • Resolution: 250×122 pixels
  • Viewing Angle: >170°
  • Display Color: black, white
  • Touch Point: 5 (max)
  • Weight: 0.043 kg

Outline Dimensions

Pinout Definition

In the Box

  1. 2.13inch Touch e-Paper HAT x1
  2. ABS case x1
  3. Screwdriver x1
  4. Thermal tape x1
  5. rubber feet 4PCS x1
  6. Screws x2

How To Install

Warranty
Δεν καλύπτεται με εγγύση απο τον Κατασκευαστή
Company
Waveshare
G. Weight
0.022kg
Display Size
2.13 "
Resolution
250x122
Display Color
  • Black-White
Touchscreen
Capacitive
