LilyGo T-Energy S3 – 18650

19-00019877
H733
Διαθέσιμο
Αποστολή σε 24 ώρες
1680
Gropbotronics Store Availability
Διαθεσιμότητα Καταστημάτων
Πληρωμή & Μεταφορικά

The LILYGO T-Energy S3 is a versatile ESP32-S3-based development board designed for low-power IoT applications, remote sensing, and battery-powered projects. Equipped with a dedicated 18650 lithium battery slot, it ensures long-term operation with USB charging support.

Key features
  • ESP32-S3 MCU with 16MB Flash and 8MB PSRAM for high-speed processing
  • HX6610S charging chip with reverse polarity protection
  • Supports USB charging (5V 500mA) for easy recharging
  • Wi-Fi 802.11 b/g/n & Bluetooth 5 (LE) for wireless communication
  • Qwiic 4-Pin STEMMA QT interface for I2C expansion
  • Compact size for easy integration into embedded projects
  • Compatible with Arduino-IDE, VS Code, and ESP-IDF for flexible development
Technical data

MCU

ESP32-S3

Flash

16MB

PSRAM

8MB

Wireless protocol

2.4 GHz Wi-Fi and Bluetooth 5 (LE)

Support language

C/C++, Micropython, Lua

Programming platforms

Arduino-IDE, VS Code, ESP-IDF

Onboard functions

Qwiic 4-Pin, BOOT + Reset, 18650 battery slot


Application examples
  • Battery-powered IoT devices: Long-term wireless sensors, automation projects.
  • Remote sensing & monitoring: Low-power communication and data collection.
  • Portable embedded systems: Energy-efficient designs for mobile applications.
  • Wearable & smart gadgets: Battery-backed Bluetooth and Wi-Fi connectivity.
  • DIY & Maker projects: Ideal for developers building compact and wireless solutions.
Package contents
  • T-Energy S3 ×1
  • Pin headers ×2

Κατασκευαστής
LILYGO
Part Number
H733
Εγγύηση
Ως εξάρτημα, δεν καλύπτεται με εγγύηση
Καθ. Βάρος
0.003kg
Board Specifications
MCU/SoC
ESP32-S3
Processor
Xtensa dual-core 32-bit LX7
Clock Speed
240 MHz
RAM
512 kB SRAM & 8 MB PSRAM
ROM
384 kB
Flash Memory
16 MB
Bluetooth
Bluetooth 5
Wi-Fi
Wi-Fi 4 – 802.11b/g/n – 2.4 GHz
Extra Features
  • Battery connector
