Threshold Carbon Monoxide Detection Sensor - 0-1000ppm

25-00016922
SEN0596
ΚατασκευαστήςDFRobot Part NumberSEN0596
Διαθέσιμο
Αποστολή σε 24 ώρες
€2680
DFRobot
+ −
Αγαπημένα
Κάνε μια ερώτηση
Gropbotronics Store Availability
Διαθεσιμότητα Καταστημάτων
Πληρωμή & Μεταφορικά

This carbon monoxide gas sensor differs from most gas sensors on the market as it does not provide specific gas concentration data. Instead, it detects whether the surrounding environment exceeds or falls below a fixed threshold. It operates on a wide voltage range of 5-24V, with high and low-level outputs.

The sensor is equipped with an indicator light for easy observation of its status, making it user-friendly. When the sensor detects a gas concentration above the threshold, it outputs a high-level signal and the indicator light illuminates. Conversely, when the concentration falls below the threshold, it outputs a low-level signal and the indicator light turns off.

Note: The threshold of this sensor is factory-fixed and cannot be modified by the user. Custom threshold parameters can be set for bulk orders.



Features
  • Threshold-based detection
  • Wide voltage range, 5-24V
  • High and low-level outputs
  • Indicator light for status observation
  • User-friendly design
Applications
  • Indoor air quality monitoring
  • Safety and occupational health
  • Environmental monitoring
  • Smart home systems
  • Research and development
Technical data
  • Power Supply Voltage: 5-24V
  • High level output range: 5-24V (Output high voltage = supply voltage)
  • Load Current: <100mA
  • Static Current: <10mA
  • Detectable Gas: Carbon Monoxide (CO)
  • Repeatability: <2% of the output value
  • Threshold: 20ppm (Factory-fixed threshold, cannot be modified by the user)
  • Maximum Load: 1000ppm
  • Response Time: <15s
  • Zero-Point Output: ±2ppm
  • Output Mode: High-level and low-level signals
  • Line sequence: Black line - OUT, Brown line - VCC, Blue line - GND
  • Pressure Range: 1±0.1 standard atmospheric pressure
  • Lifespan: 8 years (in air)
  • Storage Environment: 10°C ~ 30°C
  • Operating Temperature Range: -10°C ~ 50°C
  • Operating Humidity Range: 15% ~ 90% RH
  • Dimensions: L×W×H=30.35×47.4×47.4mm
  • Cable Length: 50cm
  • Housing Material: Black PCV0 flame-retardant material



Κατασκευαστής
DFRobot
Part Number
SEN0596
Εγγύηση
Ως εξάρτημα, δεν καλύπτεται με εγγύηση
Καθ. Βάρος
0.04kg
Τύπος Αισθητήρα
  • Αερίων
Τυπική Τάση Εισόδου
  • 5-24VDC
Ρεύμα Λειτουργίας
100mA
Διασύνδεση
  • Ψηφιακή
Πρωτόκολλο Eπικοινωνίας
  • Χωρίς
